The Elipta Luxes RGB with clear lens is an adjustable LED spotlight with a nickel-plated brass body and nine 2w RGB LEDs providing light output equivalent to a 50w halogen lamp with colour filter. It has a clear lens and provides a focused 30 degree beam for uplighting trees and focal points, or for use as an underwater spotlight in fountains and waterfalls. The ribbed body is designed to take an optional clip-on glare shield and the adjustable polycarbonate knuckle joint fits a range of mounting options including a spike, weighted base, extension pole and a tube bracket to allow mounting on fountain head pipes: mount required must be ordered separately. This is avaialble on our website. This fantastic garden light is designed for easy installation with less tools with the Patilo range of plug & play transformers, connectors, extension cables and junction boxes. It can provide automatic colour-changing lighting or a single colour light output: if the supply circuit is switched off rather than using the remote control button 2 to switch off, the same colour mode selection will automatically be chosen when the supply circuit is switched on the next time. In this way the remote control can be used to set up a colour mode which is intended to be used repeatedly without needing to select colour mode by using the remote control in line-of-sight to the RGB lights every time they are used. (Colour change synchronization of several lights over an prolonged period of light is not possible with plug & play RGB lights).

IP rating

IP68 with IP44 cable connector

Construction

Nickel-plated brass body
Operation GLMCL remote controller accessory is required to programme and control Plug&Play RGB lights: purchase GLMCL separately

Input

12v AC 25w max: requires power from a Patilo Plug&Play transformer

Light source

Nine 2w CREE led’s: 3 RED, 3 GREEN, 3 BLUE

Light output

400 lumens (Equivalent to a 50w halogen lamp with colour filter)

Beam angle

30 degrees

Installation

5m input cable with male IP44 2-pin input connector to plug into a Plug&Play transformer, extension cable, connector or junction box : an IP68 connection may be achieved by using either the GLWJB IP68 junction box or GLWCC waterproof cable connector. Adjustable polycarbonate knuckle joint fits a range of mounting options including a spike, weighted base, extension pole and a tube bracket to allow mounting on fountain head pipes

Accessories



GLAGS80 – Glare shield

GLGS – Ground mounting spike

GLWB – Weighted mounting base

GLEP – Extension Pole

GLTB – Tube bracket

For use with the Patilo range of Plug&Play transformers, connectors, extension cables and junction boxes.
