The Elipta Smoothie (stainless steel) is a stylish 12v recessed light for illuminating steps or patios which can take a choice of low energy LED lamps. The Smoothie is fitted with a flush frosted lens as standard to diffuse the lighting. The light is located by an “”O”” ring on the body into a sleeve tube so that no external screw fixings are visible. Remember that recessed steplights are in effect recessed spotlights so avoid using them facing viewpoints. Order lamps separately.
|
316 grade stainless steel |
|---|---|
|
IP65 |
|
Front bezel is attached to tubular aluminium body which unscrews into 2 halves without tools for easy lamp changing. 2m cable via rear entry cable |
|
12v |
|
38 degree beam for wider staircases or 60 degree beam for wider coverage of a narrower staircase, path or patio. MR16 warm white LED lamps include 3w or 5w for lighting across wider steps; Order lamps separately |
|
The plastic sleeve is built into the wall during construction or retrofitted into a hole cut with a coring bit: the light pushes into the tube, where it is held firmly in place by an o-ring, leaving a front plate with no visible fixing screws. Connect input cable to cable from transformer using T9962 cable joint or T9963 cable splice kit. |
|
Clip-on Colour Filters & Lenses |
Downloads
